How to Measure a Bathtub Shower Glass Door Space

Measuring the space for a bathtub shower glass door is crucial for ensuring a proper fit and functionality. Accurate measurements will help you select the right door size and avoid installation issues. Follow this guide to measure your bathtub shower space effectively.

Tools You'll Need

Measuring tape
Level
Notepad and pen for recording measurements

Step-by-Step Measurement Guide

1. Clear the Area

Remove any items around the bathtub and shower area, including towels and accessories, to create a clear workspace for measuring.

2. Measure the Width (Length)

Starting Point: Measure from the finished wall on the right side to the finished wall on the left side of the bathtub.
Record the Measurement: This will give you the total width of the opening. Ensure you measure at the top, middle, and bottom to account for any variations.

3. Measure the Height

From the Top of the Bathtub: Place the measuring tape at the top edge of the bathtub.
Measure to the Ceiling: Extend the tape up to the ceiling. This will determine the height for your glass door.

4. Check for Flat Surface

Flat Edge Measurement: Ensure that the edge of the tub has a flat surface at least 2 inches wide. This is important for proper installation of most shower doors.
